Ansell Lighting Z LED Eco LED High/Low Bay Luminaires
The Ansell Lighting Z-LED ECO range combines high performance with outstanding flexibility for industrial and commercial lighting projects. Built around the latest AZLE1/2 and AZLE2/2 luminaires, the range features selectable wattage outputs and three selectable colour temperatures (4000K, 5000K and 6500K), allowing each fitting to be configured on-site to suit the application. Delivering up to 26,000 lumens with efficacy of up to 130 lumens per watt, these luminaires help reduce energy consumption while providing powerful, uniform illumination. The rugged die-cast aluminium housing, IP66 ingress protection and IK09 impact resistance ensure dependable operation in demanding industrial environments, whilst the supplied AFIX connector and installation eye-bolt enable faster, simpler installation. Ideal for warehouses, logistics centres, manufacturing facilities and large commercial buildings, the Z-LED ECO range provides installers with a durable, adaptable and cost-effective lighting solution.
Showing 1 - 5 of 5 items
Showing 1 - 5 of 5 items
Key Features & Benefits
- Selectable wattage (Code dependent)
- 3CCT selectable: 4000K / 5000K / 6500K
- Delivers up to 26,000 lumens
- High efficacy of up to 130 lm/W
- 90° lensed diffuser for controlled, uniform light distribution
- Robust die-cast aluminium construction with powder-coated finish
- Integral heatsink for optimum thermal management
- Slim, lightweight design with integrated LED driver
- AFIX connector supplied for quicker installation
- Pre-wired with 1m cable
- Installation eye-bolt supplied as standard
- Suitable for suspension using drop rods, jack chain or catenary wire
- IP66 rated for protection against dust and water ingress
- IK09 impact-resistant construction
- CRI >80
- Operating temperature: -45°C to +45°C
- Supply voltage: 220-240V AC, 50/60Hz
- Ideal for warehouses, factories, logistics centres, workshops and industrial buildings
