Hager ARR932U 1 Module 32A 6kA 30mA SP Type A B Curve Combined AFDD + RCBO - For Domestic Installations

Hager ARR932U 1 Module 32A 6kA 30mA SP Type A B Curve Combined AFDD + RCBO - For Domestic Installations

The ARR932U is a RCBO with dangerous arc detection form Hager - 1M 32A B curve 6kA Type A 30mA

Order code: ARR932U
Manufacturer: Hager
GTIN: 3250611044819

£ 111.16 incl. VAT
£ 92.63 excl. VAT

Trade Price: £ 208.43
You SAVE
£ 115.80 or 56%
Add to compare
Normally despatched within 1-2 working days
Normally despatched
within 1-2 working days

Hager ARR932U Description

Designed within a single module the ARR932U is a combined AFDD / RCBO which will detect and disconnect dangerous electrical arcing faults, reducing the risk of fires from occurring in domestic properties.
The next generation of Arc Fault detection device (AFDD) from Hager which utilises sophisticated algorithms to monitor the electronic signatures of devices energised on a circuit. This single module device is designed to fit all Hager consumer units and is packed full of safety and fault finding features.

Hager ARR932U Features

1P+N arc fault detection device (AFDD)
Rating: 32 Amp
Trip current: 30mA
Type: B curve
Breaking capacity: 6kA
DIN rail mounted
Connection capacity: Rigid = 25mm² - Flexible = 16mm²
Number of poles: 2 - Single pole and neutral
Single Module
Voltage: 230V
Protection device which combines an RCBO with an Arc Fault Detection device
Complies with BS EN 62606 and BS EN 61009-1
