Wylex NHXS1C16 NHXS 1 Module SP&N C Curve Miniature RCBO 16A 6kA 30mA
Order code: NHXS1C16
Manufacturer: Wylex
GTIN: 5013601083223
Notify me by email when product is available
Normally despatched
within 5-7 working days
within 5-7 working days
Wylex NHXS1C16 Description
Wylex NHXS1C16 NHXS 1 Module SP&N C Curve Miniature RCBO 16A 6kA 30mA
Wylex NM series metal consumer units deliver the latest residential circuit protection approaches, whilst maintaining quality, affordability and most importantly safety.
Renowned for their top quality products, Wylex offers a range of features to make installation easier.
Features:
- All metal enclosure, no external plastic parts
- Low Smoke & Fume paint
- Non combustible cover blanks
- Compact enclosure
- Available in ‘no miss terminal’ fixed busbar versions and flexible versions
- Full metal raised & removable DIN rail / busbar assembly
- Earth and neutral terminals
- Circuit identification labels providing clear understanding of outgoing ways
- Cable entry knockouts on 5 sides, top, bottom, left, right and rear
- Mains tails cable entry grommet / gland for supplementary insulation
| Brand : | Wylex |
| Part No : | NHXS1C16 |
| GTIN : | 5013601083223 |
| Product Range : | NHXS |
| Current Rating : | 16A |
| Voltage Rating : | 230V |
| Standards : | BS 7671 |
| Mounting : | Din Rail |
| Height : | 90mm |
| Width : | 18mm |
| Guarantee : | 1 Year |
| Number of Poles : | Single Pole and Neutral |
| Number of Modules : | 1 |
| Incoming Terminal Capacity : | 0.75mm² to 16mm² |
| RCD Type : | A |
| Tripping Characteristics : | C Curve |
| Tripping Sensitivity : | 30mA |
| Short Circuit Rating : | 6kA |
| Outgoing Terminal Capacity : | 0.75mm² to 16mm² |
