BG Electrical Nexus Storm WP42 240V/20A IP66 2 Gang Weatherproof Switch Grey
The BG Electrical WP42 Nexus Storm is a 2 gang 2 way 20Ax single pole switch with neon indicator enclosed in grey IP66 weatherproof enclosure that protects the electricity supply from water and dust ingress in the most arduous of conditions.
within 1-2 working days
BG Electrical WP42 Description
The BG Electrical WP42 Nexus Storm is a 2 gang 2 way 20Ax single pole switch with neon indicator enclosed in grey IP66 weatherproof enclosure that protects the electricity supply from water and dust ingress in the most arduous of conditions.
This two-way switch can be wired for one or two way control and is suitable for controlling outdoor lighting as well as other inductive loads up to 20 Amps. The X in the 20Ax means that they are rated for fluorescent loads and don't need to be de-rated to counter for the inrush current generated by these types of light fixtures. Can be used as a direct replacement for an existing one-gang light switch.
The stylish modern profile has covers to conceal fixing screws, maintaining the IP rating. The colour coded terminals with backed out captive screws allow for quick and easy installation.
Enclosure is IP66 rated manufactured in robust high impact, UV stable, durable PVC and features cable entry knock outs on all 4 sides with removable blanking caps.
The WP42 is ideal for installation in the garden workshop, and commercial applications to control lighting and other appliances and can be used as a direct replacement for an existing two-gang light switch.
BG Electrical WP42 Features
Outdoor, all weather, waterproof, safe switches
IP66 rated
Switches manufactured to BS EN 60669-1
•Housing will accept alternative switch modules from the Grid range
Easy to install with configurable grid switches - captive terminals with clear printing
Robust, high impact, UV stable housing
Compact housing with contoured rockers
Neon indicator to show power or operation status
Clearly marked terminals with backed out captive screws for easy installation
20 Amp, 20AX inductive rated covers to seal the fixing screws
Earth terminal in mounting box
All cable entries in the 4 sides have removable blanking caps
Neon indicator can be wired to illuminate when off or on depending on wiring.
Order Code | WP42 |
Standard(s) | BS EN 60669-1 |
Rating | 20 Amp 250V~ (20AX - no derating for inductive or fluorescent loads) |
Switch type | Single pole |
Contact Gap | 3.0mm minimum |
Terminal Capacity | 4 x 1.0mm² 4 x 1.5mm² 2 x 2.5mm² 1 x 4.0mm² |
IP Rating | IP66 |
Size | 91mm x 91mm x 67mm |
Number of cable entries | 5 x 20mm. 1 in each of 3 sides and 2 in the remaining side 1 drill out entry 20/25mm in rear face |
Brand : | BG |
Part No : | WP42 |
GTIN : | 5050765022149 |
Colour : | Grey |
Product Range : | Nexus Storm |
Current Rating : | 13A |
Voltage Rating : | 250V |
IP Rating : | IP66 |
Standards : | BS 1363 Part 2 |
Number of Gangs : | 1 |
With Socket : | Yes |
Neon : | Yes |
Terminal Capacity : | 3 x 2.5mm² 3 x 4mm² 2 x 6.0mm² |
Type : | 1 Gang Outdoor Switchsocket |
Dimensions : | 111mm x 154mm x 80mm |
