EO Chargers EM301-T2T-PME-DCL Mini Pro3 7.2kW 32A 1Ph 230V AC Tethered EV Charger With Single Type 2 Gun & Lead - Black

EO Charging EM301-T2T-PME-DCL Description

The EO Charging Mini Pro3 EM301-T2T-PME-DCL is a stylish black single phase 230V AC 5m tethered EV charger that focusses on connectivity and reliability in a unit the size of an A5 notebook.

Fast charging capacity of 7.2kW 32A complete with Type 2 connector and 5m tethered cable that can be wall or post mounted indoor or outdoors (IP66 weather resistant). Perfect for overnight or high-speed charging.

Connects to your solar panels using a solar matching functionality - charge your car with EO solar matching or net-zero technologies (optional extra, using an additional CT clamp).

Wi-Fi, Cat5 Ethernet, Bluetooth connectivity as standard with 4G cellular as optional extra. Controllable from a smart device with the iOS or Android EO Smart Home app, allowing users to set-up and maintain custom charging schedules.

Built-in PME – no need for earth rods with built in open PEN conductor protection. Dynamic load management via OCPP or locally via CT clamp preventing energy blackouts at home. DC leakage detection, no Type B RCD required.

OCPP-compliant – future-proof with OCPP. 1.6J as standard and additional security extensions.

Simple electrical installation with adjustable maximum charging current for lower rated supplies.

EO Charging EM301-T2T-PME-DCL Features

• EO Charging EM301-T2T-PME-DCL 1Ph tethered EV charger
• Type 2 connector and 5m tethered cable
• Black A5 notebook size enclosure
• Enclosure: PC UV stabilized (UL94 V-0 fire rated)
• IP66 weather resistant
• 7.2kW 32A fast charging capacity
• Voltage Rating: 230V AC
• Connects to your solar panels using a solar matching functionality
• Connectivity – Wi-fi, Bluetooth & Cat  Ethernet as standard. 4G cellular as optional extra
• EO Smart Home app for iOS or Android
• Monitor energy usage and set charging schedules
• OCPP 1.6J: ready for open OCPP integration
• Built-in PME: No need for earth rods with built in open PEN conductor protection
• Integral 6mA DC leakage detection, no Type B RCD required
• Dynamic load management via OCPP
• Adjustable maximum charging current for lower rated supplies
• TN & IT grid connections
• Perfect for overnight or high-speed charging
• Safe when installed both indoor or outdoor
• Simple electrical installation
• Dimensions: Height: 230mm | Width: 151mm | Depth: 100mm
